PVC Sleeves

PVC Sleeves
PVC Sleeves
Product Code : PS 05
Brand Name : SGI
Product Description

We are placed amongst the renowned manufacturers, exporters and suppliers of a comprehensive range of PVC Sleeves. Offered sleeves are manufactured using excellent quality raw material and avant-garde technology by our dexterous professionals. The sleeves are used before wires are connected to any type of terminal for the protection of cable harnesses. Furthermore, our clients can avail this PVC Sleeves from us in varied specifications as per their exact requirements.

FEATURES

  • Widely used for protection of cable harnesses.
  • To be used before wires are connected to any type of terminal.

PVC Sleevings
Back
Features

  • Made from premium virgin PVC compound developed in-house by SGI for 75 Deg C applications.
  • Also available in lead free material confirming to ROHS norms.
  • Widely used in all electrical and automobile wiring Harnesses.
  • Imparts higher mechanical and insulation properties.

Features:

  • Excellent strength
  • Longer service life
  • Durable finish
  • Robust construction

Benefits:

  • Widely used for protection of cable harnesses.
  • To be used before wires are connected to any type of terminal.

Item No

Inner Diameter (in mm)

Wall Thickness (in mm)

Std Colors

Std Packing

SL0.5X

0.50

0.40

Black, Red, Blue, Yellow, Green

100 mtr Coil

SL1X

1.00

0.40

"

"

SL1.5X

1.50

0.40

"

"

SL2X

2.00

0.40

"

"

SL2.5X

2.50

0.40

"

"

SL3X

3.00

0.40

"

"

SL3.5X

3.50

0.40

"

"

SL4X

4.00

0.40

"

"

SL5X

5.00

0.40

"

30 mtr Coil

SL6X

6.00

0.50

"

"

SL7X

7.00

0.50

"

"

SL8X

8.00

0.50

"

"

SL9X

9.00

0.50

"

"



Item No

Inner Diameter (in mm)

Wall Thickness (in mm)

Std Colors

Std Packing

SL10X

10.00

0.50

Black, Red, Blue, Yellow, Green

30 mtr Coil

SL12X

12.00

0.55

"

"

SL14X

14.00

0.75

"

"

SL15X

15.00

0.75

"

"

SL16X

16.00

0.75

"

"

SL18X

18.00

0.75

"

"

SL20X

20.00

0.75

"

"

SL22X

22.00

0.75

"

"

SL25X

25.00

0.75

"

"

SL30X

30.00

1.00

Black

"

SL32X

32.00

1.00

"

"

SL35X

35.00

1.00

"

"

SL40X

40.00

1.00

"

"

SL50X

50.00

1.25

"

"

Item No.

Inner Diameter (in mm)

Wall Thickness (in mm)

Suitable for cable size

Standard Colors

Standard Packing

SL0.5X

0.50

0.40


Black, Red, Blue, Yellow, Green and Transparent

100 Mtr Roll

SL1X

1.00

0.40


SL2X

2.00

0.40

0.35 sq.mm

SL3X

3.00

0.40

0.50 sq.mm

SL4X

4.00

0.40

2.50 sq.mm

SL6X

6.00

0.50

6.00 sq.mm

SL8X

8.00

0.50

16.0 sq.mm

SL1.5X

1.50

0.40

0.25 sq.mm

SL2.5X

2.50

0.40

0.50 sq.mm

SL3.5X

3.50

0.40

1.0 sq.mm

SL5X

5.00

0.40

4.0 sq.mm

SL7X

7.00

0.50

10.0 sq.mm

30 mtr Roll

SL9X

9.00

0.50

16.0 sq.mm

SL10X

10.00

0.50

25.0 sq.mm

SL12X

12.00

0.55

35.0 sq.mm

Black, Red, Blue, Yellow, Green and Transparent

30 Mtr Roll

SL18X

18.00

0.75

95.0 sq.mm

SL22X

22.00

0.75

150.0 sq.mm

SL30X

30.00

1.00

240.0 sq.mm

SL35X

35.00

1.00

300.0 sq.mm

SL50X

50.00

1.25

500.0 sq.mm

SL15X

15.00

0.75

70.0 sq.mm

SL20X

20.00

0.75

120.0 sq.mm

SL25X

25.00

0.75

185.0 sq.mm

SL32X

32.00

1.00

280.0 sq.mm

Black

SL40X

40.00

1.00

400.0 sq.mm

SL14X

14.00

0.75

50.0 sq.mm

SL16X

16.00

0.75

70.0 sq.mm

Technical Specifications

Name of the Test

Test Method

Unit

Results specified

Result observed

Tensile strength

IS 10810:7

N/mm2

12.5

13.26

Elongation at break

IS 10810:7

%

150 minimum

171

Heat test

IS 10810:14


No cracks should appear

No crack observed

Thermal stability

IS 10810:19

Mins

40 minutes

45

Loss of mass

IS 10810:10

MG/CM

2

1.6

Hot deformation

IS 10810:15

%

50% maximum

43

Shrinkage

IS 10810:12

%

4% maximum

2.8

Cold bend test

IS 10810:20


No cracks should appear

No cracks observed

Dielectric test

IS 10810:43

OHM-CM

1x1013

1.8x1015

Color fastness test

IS 10810:18


No change on filter paper

No change in colour observed

High volt test

IS 10810:45

KV

5 minutes at 3KV

Sample withstood at 3kv for 5mins

Flammability test

UL-94



Vo
